What is the flow rating of the Quincy QED-85 air dryer?

The Quincy QED-85 is rated at 85 SCFM.

What type of air dryer is the Quincy QED-85?

The Quincy QED-85 is a Refrigerated Cycling air dryer.

What pressure dewpoint does the Quincy QED-85 achieve?

The Quincy QED-85 achieves a pressure dewpoint of 38°F.

What voltage does the Quincy QED-85 require?

The Quincy QED-85 runs on 115V 60Hz 1-Ph.

Quincy QED-85

Quincy QED-85 is an 85-SCFM cycling refrigerated air dryer delivering a 38 deg F pressure dewpoint at up to 232 PSI maximum inlet pressure, with a 120 deg F maximum inlet temperature and 37 deg F maximum ambient temperature. Powered by a 0.079 kW motor on 115V 60Hz single-phase power, it uses R134a refrigerant and connects via 1 in NPT. The unit weighs 127 lbs, making it suitable for light industrial shops needing protected air at moderate flow rates.

Flow

85 SCFM

Dew point

38 °F

Purge loss

— %

Max PSI

232 PSI

Air output per kW inputAirflow per kW input

126.9SCFM/kW

Poor 30Typical 50Good 75

Pressure dew pointClass typical · refrigerated · cycling

38°F

Warmer +30°Class typ 38°FDrier −30°

Price per cubic foot · minuteVerified retailer price

$58$/SCFM

Good $180Typical $280High $420

PERFORMANCE

Catalog flow85 SCFM @ 232 PSI

Pressure dew point38°F

Purge loss0% (no purge — refrigerated)

SCFM / kW126.9 SCFM/kW

Best fitGeneral shop air drying with energy savings at part-load

INLET & OPERATING CONDITIONS

Inlet PSI rangeup to 232 PSI

Max inlet temp120°F

Max ambient120°F

ELECTRICAL & FORM

Power0.67 kW

Electrical service115V 60Hz 1-Ph

RefrigerantR134a

Weight127 lb

COST & OWNERSHIP

Yearly estimates assume 8 hr/day · 250 day/yr at $0.13/kWh. Adjust to your shop’s actual utilization for a precise number.

Electric · yearlyEst. $174

Manufacturer Brochure Pdfview · download PDF local copy

Where this sits in the catalog

Compared against 15 other refrigerated · cycling dryers in the catalog.

Flow capacity85scfm
10 scfmmedian 50 scfm200 scfm
+70% vs. median
Pressure dew point38°F
38°Fmedian 38°F39°F
0°F vs. median
Price$4,896
$2,052median $4,141$8,633
+18.2% vs. median
