QED-150

Quincy QED-150 is a 150-SCFM cycling refrigerated air dryer delivering a 38 deg F pressure dewpoint at up to 232 PSI maximum inlet pressure, with a 120 deg F maximum inlet temperature and 37 deg F maximum ambient temperature. Powered on 208-230V 60Hz single-phase power with R-410A refrigerant and 1 in NPT-F connections, the unit weighs 200 lbs. The larger frame and R-410A refrigerant allow higher flow capacity versus the QED-85 and QED-100 variants in the same series. Cycling operation reduces power draw during partial load. The QED-150 is suited for mid-size machine shops, spray finishing operations, and multi-compressor installations needing consistent moisture protection. Quincy Compressor provides broad dealer and service coverage. Retail price is approximately $6,900. Remaining gaps: OEM datasheet URL not confirmed; minimum inlet PSI not specified.
