Hankison (SPX FLOW) · HHL · DESICCANT · HEATLESS

HHL-260

260 SCFM · -40°F dew point · 15% purge · 150 PSI max
PRICE
Unverified
no price source on file
Hankison (SPX FLOW) HHL-260

Hankison HHL-260, marketed under the SPX FLOW brand, is a heatless desiccant compressed-air dryer rated at 260 SCFM at standard inlet conditions, delivering a -40°F pressure dew point. Maximum inlet pressure is 150 PSI. The unit connects via 1-1/2 NPT port with 115V / 60 Hz / single-phase power. At 1,010 lbs, the HHL-260 is a large dual-tower desiccant dryer designed for industrial compressed-air systems requiring ISO 8573-1 Class 2 moisture performance at high flow rates — suited for large manufacturing facilities, automotive paint booths, instrumentation air networks, and food or pharmaceutical processing. Heatless desiccant designs consume approximately 15–18% of dried output air for tower regeneration; account for purge loss in total system design. Hankison is a legacy industrial brand under SPX FLOW, sold through authorized distributors with dealer-quoted pricing. A factory datasheet is available confirming flow and dewpoint ratings.

Flow
260 SCFM
Dew point
-40 °F
Purge loss
15 %
Max PSI
150 PSI
Air output per kW inputNo flow/power on file
—SCFM/kW
Poor 35Typical 60Good 90
Pressure dew pointClass typical · desiccant · heatless
-40°F
Warmer +30°Class typ -40°FDrier −30°
Price per cubic foot · minuteNo price source on file
—$/SCFM
Good $180Typical $280High $420
PERFORMANCE
Catalog flow260 SCFM @ 150 PSI
Pressure dew point-40°F
Purge loss15%
Rating conditions100 psig / 100°F inlet / 100°F ambient
Regen cycle10-minute NEMA cycle (energy-saving)
Best fitLarge industrial compressed air drying for 260 SCFM systems requiring -40 F pressure dewpoint; available in four ISO purity classes
INLET & OPERATING CONDITIONS
Inlet PSI range60–150 PSI
Max inlet temp120°F
Max ambient120°F
Connections2-inch NPT
ELECTRICAL & FORM
Electrical service100-240V 1-Ph 50-60Hz
Weight1010 lb
Dimensions72 x 49 x 38 in (HxWxD)
COST & OWNERSHIP
Yearly estimates assume 8 hr/day · 250 day/yr at $0.13/kWh. Adjust to your shop’s actual utilization for a precise number.
Purge cost · yearlyEst. $2,340
Brochureview · download PDF local copy

Where this sits in the catalog

Compared against 25 other desiccant · heatless dryers in the catalog.

  • Flow capacity260scfm
    6 scfmmedian 113.5 scfm1,500 scfm
    +129.1% vs. median
  • Pressure dew point-40°F
    -40°Fmedian -40°F-5°F
    0°F vs. median
  • Purge loss15%
    15%median 15%18.5%
    0 pts vs. median
Where this is soldPricing pending verification
