ELGi EQ022C-125AS-120B-G2-230/3 is a refrigerated air dryer integrated with a tank-mounted rotary screw air compressor delivering 134 SCFM at up to 125 PSI inlet pressure on 230V 3-phase power, achieving a pressure dewpoint of 37 deg F (3 deg C) and meeting ISO 8573-1 Class 4 moisture classification. The unit weighs 620 lbs; the 22 kW (30 HP) rating belongs to the package’s rotary screw compressor motor, and ELGi does not publish a separate power draw for the dryer section. The EQ022C model integrates a 22 kW rotary screw air compressor with the dryer section in a single tank-mounted package at 125 PSI system pressure, simplifying installation for facilities needing all-in-one compressed air treatment. At 134 SCFM, this dryer is suited for 25-30 HP rotary screw systems in manufacturing and industrial process applications requiring consistent moisture control. List price is approximately $21,698 through authorized ELGi distributors. Locate authorized service and installation partners through the installer directory on this site.
Where this sits in the catalog
Compared against 124 other air dryer dryers in the catalog.
- Flow capacity134scfm7 scfmmedian 75 scfm2,500 scfm+78.7% vs. median
- Pressure dew point37°F36°Fmedian 38°F50°F-1°F vs. median
- Price$21,698$852median $11,263$38,727+92.6% vs. median
Price history
Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.
