Atlas Copco · CD · DESICCANT · HEATLESS

CD 10+

21.2 SCFM · -40°F dew point · 15% purge · 232 PSI max
PRICE
Unverified
no price source on file
Atlas Copco CD 10+

Atlas Copco CD 10+ is a heatless desiccant compressed-air dryer rated at 21.2 SCFM at standard inlet conditions, delivering a -40°F pressure dew point. Maximum inlet pressure is 232 PSI. The unit connects via 1/2 NPT port with 115V / 60 Hz / single-phase power. The CD 10+ uses pressure-swing adsorption to achieve ISO 8573-1 Class 2 moisture performance, making it appropriate for instrumentation air, critical process equipment, electronics manufacturing, and pharmaceutical applications. As a heatless desiccant design, a portion of dried air (typically 15–20%) is consumed for desiccant bed regeneration — factor purge loss into system sizing. The CD+ series is an Atlas Copco industrial product line distributed through authorized Atlas Copco dealers with dealer-quoted pricing. A factory datasheet is available confirming flow and dewpoint ratings.

Flow
21.2 SCFM
Dew point
-40 °F
Purge loss
15 %
Max PSI
232 PSI
Air output per kW inputNo flow/power on file
—SCFM/kW
Poor 35Typical 60Good 90
Pressure dew pointClass typical · desiccant · heatless
-40°F
Warmer +30°Class typ -40°FDrier −30°
Price per cubic foot · minuteNo price source on file
—$/SCFM
Good $180Typical $280High $420
PERFORMANCE
Catalog flow21.2 SCFM @ 232 PSI
Pressure dew point-40°F
Purge loss15%
Rating conditions100 psig / 100°F inlet / 100°F ambient
Regen cycle10-minute NEMA cycle
Best fitPoint-of-use and small-system drying at -40°F dewpoint
INLET & OPERATING CONDITIONS
Inlet PSI rangeup to 232 PSI
Max inlet temp122°F
Max ambient122°F
Connections1/2 NPT
ELECTRICAL & FORM
Electrical service115V 60Hz 1-Ph
Weight55 lb
COST & OWNERSHIP
Yearly estimates assume 8 hr/day · 250 day/yr at $0.13/kWh. Adjust to your shop’s actual utilization for a precise number.
Purge cost · yearlyEst. $191
Brochureview · download PDF local copy

Where this sits in the catalog

Compared against 25 other desiccant · heatless dryers in the catalog.

  • Flow capacity21.2scfm
    6 scfmmedian 113.5 scfm1,500 scfm
    -81.3% vs. median
  • Pressure dew point-40°F
    -40°Fmedian -40°F-5°F
    0°F vs. median
  • Purge loss15%
    15%median 15%18.5%
    0 pts vs. median
Where this is soldPricing pending verification
