What horsepower is the Schulz 970.3890-0 air compressor?

The Schulz 970.3890-0 is rated at 7.5 HP.

How much air does the Schulz 970.3890-0 produce?

The Schulz 970.3890-0 delivers 25 SCFM at 125 PSI.

What size tank does the Schulz 970.3890-0 have?

The Schulz 970.3890-0 has a 60-gallon tank.

Is the Schulz 970.3890-0 single-stage or two-stage?

The Schulz 970.3890-0 is a single-stage compressor.

What voltage does the Schulz 970.3890-0 require?

The Schulz 970.3890-0 runs on 230/1/60.

What is the duty cycle of the Schulz 970.3890-0?

The Schulz 970.3890-0 has a 100% duty cycle.

What is the Schulz 970.3890-0 best for?

The Schulz 970.3890-0 is best suited for Light industrial, auto shops requiring continuous duty rotary screw air supply.

Schulz 970.3890-0 – 7.5 HP 60-Gallon 1-Stage Air Compressor

The Schulz 970.3890-0 (SRP-3008 Compact) is a 7.5 HP (5.5 kW) oil-injected belt-drive rotary screw air compressor delivering 25 CFM at 125 PSI into a 60-gallon horizontal ASME tank. Runs on 230V single-phase; noise 83 dB(A); discharge 1/2″. Designed for light industrial and auto shop applications requiring continuous-duty compressed air. Warranty: 1 year unit, 2 years on the pump.

7.50

CFM

25 @ 125 PSI

Duty

100% continuous

Tank size

60 gal

Air output per horsepowerAirflow per motor HP

3.33CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage piston

58%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$256$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage recip

Cylinder—

Pump RPM—

Lubrication—

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM25 @ 125 PSI

CFM / HP3.33

Cut-in / out—

Tank fill—

Est. draw6.6 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $2,363

Maintenance · yearlyEst. $188

Savings with Compressor Controller · yearlyEst. $544–$993

ELECTRICAL & FORM

Serviceelectric

Voltage230/1/60

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight443 lb

Form— · 60 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 181 · 7.5 HP

Sizing & pricevs. 181 in class

SCFM @ 7.5 HP25cfm
20median 2457
+4.2% vs. median
Average price$6,403
$1,698median $5,117$19k
+25.1% vs. median

Efficiency vs. peersvs. 181 in class

CFM per HP3.33cfm/hp
2.67median 3.27.65
+4.2% vs. median
Price per CFM$323$/scfm
$73median $208$632
+54.7% vs. median
