What horsepower is the Schulz 15120VW60X-3 air compressor?

The Schulz 15120VW60X-3 is rated at 15 HP.

How much air does the Schulz 15120VW60X-3 produce?

The Schulz 15120VW60X-3 delivers 45 SCFM at 175 PSI.

What size tank does the Schulz 15120VW60X-3 have?

The Schulz 15120VW60X-3 has a 120-gallon vertical_tank tank.

Is the Schulz 15120VW60X-3 single-stage or two-stage?

The Schulz 15120VW60X-3 is a two-stage compressor.

What voltage does the Schulz 15120VW60X-3 require?

The Schulz 15120VW60X-3 runs on 460V/3ph.

What is the Schulz 15120VW60X-3 best for?

The Schulz 15120VW60X-3 is best suited for Industrial facilities, large shops requiring 45 CFM continuous.

Schulz 932.9368-0-460/3 – 15 HP 120-Gal 2-Stage Compressor

The Schulz 15120VW60X-3 (MPN 932.9368-0-460/3) is a 15 HP two-stage V-Series cast-iron reciprocating air compressor delivering 45 SCFM at 175 PSI (60 CFM max displacement) into a 120-gallon vertical ASME tank. Runs on 460V three-phase with a 3-piston W-cylinder pump, splash lubrication, belt drive, and prewired magnetic starter. Suited for industrial facilities and large shops. Warranty: 2 years on the pump.

CFM

45 @ 175 PSI

Duty

— continuous

Tank size

120 gal

Air output per horsepowerAirflow per motor HP

3CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 2-stage piston

67%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$187$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages2-stage recip

Cylinder—

Pump RPM—

Lubricationsplash

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercoolerfinned-tube between-stage

PERFORMANCE

Catalog CFM45 @ 175 PSI

CFM / HP3

Cut-in / out145 / 175 PSI

Tank fill—

Est. draw13.2 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $4,727

Maintenance · yearlyEst. $375

Savings with Compressor Controller · yearlyEst. $1,087–$1,985

ELECTRICAL & FORM

Serviceelectric

Voltage460V/3ph

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight938 lb

FormVertical_tank · 120 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 83 · 15 HP

Sizing & pricevs. 83 in class

SCFM @ 15 HP45cfm
17median 51111
-11.8% vs. median
Average price$8,399
$4,621median $9,585$25k
-12.4% vs. median

Efficiency vs. peersvs. 83 in class

CFM per HP3cfm/hp
1.15median 3.47.44
-11.8% vs. median
Price per CFM$194$/scfm
$96median $188$443
+2.8% vs. median
