What horsepower is the Schulz 932.9322-P-230/3 air compressor?

The Schulz 932.9322-P-230/3 is rated at 7.5 HP.

How much air does the Schulz 932.9322-P-230/3 produce?

The Schulz 932.9322-P-230/3 delivers 21.6 SCFM at 175 PSI.

What size tank does the Schulz 932.9322-P-230/3 have?

The Schulz 932.9322-P-230/3 has a 80-gallon vertical tank.

Is the Schulz 932.9322-P-230/3 single-stage or two-stage?

The Schulz 932.9322-P-230/3 is a two-stage compressor.

What voltage does the Schulz 932.9322-P-230/3 require?

The Schulz 932.9322-P-230/3 runs on 230V 3-Phase.

What is the Schulz 932.9322-P-230/3 best for?

The Schulz 932.9322-P-230/3 is best suited for industrial.

Schulz 932.9322-P-230/3 – 7.5 HP 80-Gallon Air Compressor

The Schulz 932.9322-P-230/3 is a 7.5 HP two-stage reciprocating air compressor on an 80-gallon vertical tank, rated for 21.6 SCFM at 175 PSI with splash lubrication. Suited for body shops, tire shops, and light industrial applications requiring reliable three-phase air from a compact vertical footprint.

7.50

CFM

21.6 @ 175 PSI

Duty

— continuous

Tank size

80 gal

Air output per horsepowerAirflow per motor HP

2.88CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 2-stage piston

67%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$167$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages2-stage recip

Cylinder—

Pump RPM—

Lubricationsplash

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM21.6 @ 175 PSI

CFM / HP2.88

Cut-in / out—

Tank fill—

Est. draw6.6 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $2,363

Maintenance · yearlyEst. $188

Savings with Compressor Controller · yearlyEst. $544–$993

ELECTRICAL & FORM

Serviceelectric

Voltage230V 3-Phase

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight571 lb

FormVertical · 80 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 181 · 7.5 HP

Sizing & pricevs. 181 in class

SCFM @ 7.5 HP21.6cfm
20median 2457
-10% vs. median
Average price$6,164
$1,698median $5,117$19k
+20.5% vs. median

Efficiency vs. peersvs. 181 in class

CFM per HP2.88cfm/hp
2.67median 3.27.65
-10% vs. median
Price per CFM$296$/scfm
$73median $208$632
+41.7% vs. median
