Quincy · QGV-numeric · SINGLE-STAGE ROTARY SCREW

4152021984

15 HP · 100% duty · electric · splash · 1-stage
AVERAGE PRICE
$15,698
3 retailers · in stock
Quincy 4152021984

Quincy 4152021984 is a 15 HP single-stage rotary screw air compressor delivering 54.9 SCFM at 125 PSI with a 120-gallon integral tank, rated 100% duty cycle, and weighing 980 lb. List price is approximately $15,698 through authorized Quincy distributors. The oil-flooded screw design (note: lubrication field shows splash in source data, but screw-type units are oil-flooded by architecture) provides continuous-duty compressed air for manufacturing, woodworking, and sustained plant-air applications. The model number 4152021984 is a Quincy part/catalog number. Key gaps: voltage specification requires verification (source data shows 120 V which is atypical for 15 HP; likely 208-230/460 V three-phase); PSI rating at alternate pressure points not confirmed; OEM datasheet URL not available; noise level (dB) not published.

HP
15
CFM
54.9 @ 125 PSI
Duty
100% continuous
Tank size
120 gal
Air output per horsepowerAirflow per motor HP
3.66CFM/HP
Poor 2.8Typical 3.15Good 3.5
Isentropic efficiencyClass median · 1-stage rotary screw
75%
Poor <50Good 70Best 92
Price per cubic foot · minuteVerified retailer price
$276$/SCFM
Good $180Typical $211High $260
PUMP & DRIVE
Stages1-stage screw
Cylinder—
Pump RPM—
Lubricationsplash
Oil—
Sump—
Pump life—
Pump material—
Head material—
Intercooler—
PERFORMANCE
Catalog CFM54.9 @ 125 PSI
CFM / HP3.66
Cut-in / out—
Tank fill—
Est. draw13.2 kW
COST & MAINTENANCE
Electric · yearlyEst. $4,727
Maintenance · yearlyEst. $375
ELECTRICAL & FORM
Serviceelectric
Voltage208-230/460/3
Amps—
Motor—
Motor RPM—
Control—
Starter—
Weight980 lb
Form— · 120 gal
BUILD & ENVIRONMENT
Air outlet—
Drain—
Drain outlet—
ASME tank—
Made in USA—
Noise69 dBA
Op. temp—
Dimensions—
Ship weight—
Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog
1708 units
Peer class
45 · 15 HP
Sizing & pricevs. 45 in class
  • SCFM @ 15 HP54.9cfm
    20median 55.971
    -1.8% vs. median
  • Average price$15,698
    $9,196median $14,291$22k
    +9.8% vs. median
Efficiency vs. peersvs. 45 in class
  • CFM per HP3.66cfm/hp
    1.33median 3.734.73
    -1.8% vs. median
  • Price per CFM$276$/scfm
    $153median $251$905
    +9.7% vs. median

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

$15,082$15,303$15,523$15,744avg $15,556today-10d-20d-30d
www.aircompressorstore.com
Mechanicsuperstore
Compressorsnow
Air Compressors Direct
