What horsepower is the Jenny J5A-80 air compressor?

The Jenny J5A-80 is rated at 5 HP.

How much air does the Jenny J5A-80 produce?

The Jenny J5A-80 delivers 28.8 SCFM.

What is the maximum pressure of the Jenny J5A-80?

The Jenny J5A-80 has a maximum operating pressure of 125 PSI.

What size tank does the Jenny J5A-80 have?

The Jenny J5A-80 has a 80-gallon tank.

Is the Jenny J5A-80 single-stage or two-stage?

The Jenny J5A-80 is a single-stage compressor.

What voltage does the Jenny J5A-80 require?

The Jenny J5A-80 runs on 230/1ph.

Is the Jenny J5A-80 oil-free or oil-lubricated?

The Jenny J5A-80 is oil-lubricated.

Jenny J5A-80 – 5 HP 80-Gallon 1-Stage Air Compressor

The Jenny J5A-80 is a 1-stage oil-lubricated reciprocating industrial air compressor, driven by a 5.00 HP motor, with a 80.0-gallon tank, operating on 230/1phV power. Maximum operating pressure is 125 PSI. The simplex configuration is designed for stationary industrial use. Unit weight is 675 lbs. List price is approximately $2,764 USD; current pricing available through authorized distributors. Contact an authorized Jenny distributor for current availability, warranty terms, and installation support.

CFM

28.8 @ 125 PSI

Duty

— continuous

Tank size

80 gal

Air output per horsepowerAirflow per motor HP

5.76CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage piston

58%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$96$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage recip

Cylinder—

Pump RPM780 rpm

Lubricationoil-lubricated

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM28.8 @ 125 PSI

CFM / HP5.76

Cut-in / out—

Tank fill—

Est. draw4.4 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $1,576

Maintenance · yearlyEst. $125

Savings with Compressor Controller · yearlyEst. $362–$662

ELECTRICAL & FORM

Serviceelectric

Voltage230/1ph

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight675 lb

Form— · 80 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 157 · 5 HP

Sizing & pricevs. 157 in class

SCFM @ 5 HP28.8cfm
10median 17.238
+67.4% vs. median
Average price$2,764
$962median $4,178$17k
-33.9% vs. median

Efficiency vs. peersvs. 157 in class

CFM per HP5.76cfm/hp
2.08median 3.447.64
+67.4% vs. median
Price per CFM$145$/scfm
$77median $228$864
-36.3% vs. median
