PRICE
Unverified
no price source on file
Ingersoll Rand R110i is a 125-200 hp-class single-stage fixed-speed rotary-screw compressor delivering 733 CFM (20.76 m³/min) FAD per ISO 1217:2009 Annex C. Air-cooled (water-cooled variant available) cooling, progressive adaptive control (pac) with intellisys microprocessor control, rated for continuous duty.
HP
150
CFM
690 @ 110 PSI
Duty
— continuous
Tank size
— gal
Air output per horsepowerAirflow per motor HP
4.60CFM/HP
Poor 2.8Typical 3.15Good 3.5
Isentropic efficiencyClass median · 1-stage rotary screw
75%
Poor <50Good 70Best 92
Price per cubic foot · minuteNo price source on file
—$/SCFM
Good $180Typical $211High $260
PUMP & DRIVE
Stages1-stage screw
Cylinder—
Pump RPM—
Lubrication—
Oil—
Sump—
Pump life—
Pump material—
Head material—
Intercooler—
PERFORMANCE
Catalog CFM690 @ 110 PSI
CFM / HP4.60
Cut-in / out—
Tank fill—
Est. draw131.6 kW
COST & MAINTENANCE
Electric · yearlyEst. $47,267
Maintenance · yearlyEst. $3,750
ELECTRICAL & FORM
Service—
Voltage460/3/60
Amps—
Motor—
Motor RPM1750 rpm
Control—
Starter—
Weight5620 lb
Form—
BUILD & ENVIRONMENT
Air outlet—
Drain—
Drain outlet—
ASME tank—
Made in USAYes
Noise76 dBA
Op. temp40–104 °F
Dimensions106 x 58 x 80 in
Ship weight—
Warranty—
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1655 units
- Peer class
- 2 · 150 HP
Sizing & pricevs. 2 in class
- SCFM @ 150 HP690cfm690median 720750-4.2% vs. median
Efficiency vs. peersvs. 2 in class
- CFM per HP4.6cfm/hp4.6median 55-8% vs. median
Where this is soldPricing pending verification
