Industrial Gold · R-Series · SINGLE-STAGE ROTARY SCREW

R101V80

10 HP · Vertical · 100% duty · electric · oil-flooded · 1-stage
AVERAGE PRICE
$14,928
1 retailer
Industrial Gold R101V80

Industrial Gold R101V80 is a 10 HP oil-flooded rotary screw industrial air compressor delivering 37 SCFM on an 80-gallon vertical tank, wired for 208-230V single-phase. The R101 designation identifies an Industrial Gold R-series rotary screw airend, suited to auto shops, fleet maintenance bays, and body shops. The rotary screw airend at 10 HP delivers smooth 37 SCFM output for moderate shop air demand. The 80-gallon vertical receiver reduces motor cycling under normal tool usage patterns. 208-230V single-phase power suits standard commercial electrical service. Key gaps: rated PSI operating point, duty cycle, weight, and OEM datasheet URL not confirmed in current record.

HP
10
CFM
37 @ 125 PSI
Duty
100% continuous
Tank size
80 gal
Air output per horsepowerAirflow per motor HP
3.70CFM/HP
Poor 2.8Typical 3.15Good 3.5
Isentropic efficiencyClass median · 1-stage rotary screw
75%
Poor <50Good 70Best 92
Price per cubic foot · minuteVerified retailer price
$403$/SCFM
Good $180Typical $211High $260
PUMP & DRIVE
Stages1-stage screw
Cylinder
Pump RPM
Lubricationoil-flooded
Oil
Sump
Pump life
Pump material
Head material
Intercooler
PERFORMANCE
Catalog CFM37 @ 125 PSI
CFM / HP3.70
Cut-in / out
Tank fill
Est. draw8.8 kW
COST & MAINTENANCE
Electric · yearlyEst. $3,151
Maintenance · yearlyEst. $250
ELECTRICAL & FORM
Serviceelectric
Voltage208-230
Amps
Motor
Motor RPM
Control
Starter
Weight
FormVertical · 80 gal
BUILD & ENVIRONMENT
Air outlet
Drain
Drain outlet
ASME tank
Made in USA
Noise
Op. temp
Dimensions
Ship weight
Warranty

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog
1655 units
Peer class
59 · 10 HP
Sizing & pricevs. 59 in class
  • SCFM @ 10 HP37cfm
    20median 39.845
    -6.9% vs. median
  • Average price$14,928
    $4,547median $11,392$26k
    +31% vs. median
Efficiency vs. peersvs. 59 in class
  • CFM per HP3.7cfm/hp
    2median 44.5
    -7.5% vs. median
  • Price per CFM$403$/scfm
    $185median $282$903
    +42.8% vs. median

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

$14,182$14,679$15,177$15,675avg $14,928today-10d-20d-30d
