What horsepower is the Hertz HVD15-Base-460/3-150 air compressor?

The Hertz HVD15-Base-460/3-150 is rated at 20 HP.

How much air does the Hertz HVD15-Base-460/3-150 produce?

The Hertz HVD15-Base-460/3-150 delivers 92 SCFM at 100 PSI.

What is the maximum pressure of the Hertz HVD15-Base-460/3-150?

The Hertz HVD15-Base-460/3-150 has a maximum operating pressure of 150 PSI.

What size tank does the Hertz HVD15-Base-460/3-150 have?

The Hertz HVD15-Base-460/3-150 has a 0-gallon tank.

Is the Hertz HVD15-Base-460/3-150 single-stage or two-stage?

The Hertz HVD15-Base-460/3-150 is a single-stage compressor.

What voltage does the Hertz HVD15-Base-460/3-150 require?

The Hertz HVD15-Base-460/3-150 runs on 230/3ph.

Is the Hertz HVD15-Base-460/3-150 oil-free or oil-lubricated?

The Hertz HVD15-Base-460/3-150 is oil-free.

Hertz HVD15-Base-460/3-150

Hertz HVD15-Base-460/3-150 is a 20.00 HP single-stage simplex air compressor delivering 92.00 CFM @ 100 PSI, 230/3ph. oil-free-lubricated pump. shipping weight 772 lb. Listed at approximately $20182.00 through industrial distributors.

CFM

92 @ 100 PSI

Duty

— continuous

Tank size

— gal

Air output per horsepowerAirflow per motor HP

4.60CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage rotary screw

75%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$219$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage screw

Cylinder—

Pump RPM—

Lubricationoil-free

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM92 @ 100 PSI

CFM / HP4.60

Cut-in / out—

Tank fill—

Est. draw17.6 kW

COST & MAINTENANCE

Electric · yearlyEst. $6,302

Maintenance · yearlyEst. $500

ELECTRICAL & FORM

Serviceelectric

Voltage230/3ph

Amps—

Motor—

Motor RPM—

ControlVSD frequency converter

Starter—

Weight772 lb

Form—

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise72 dBA

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 42 · 20 HP

Sizing & pricevs. 42 in class

SCFM @ 20 HP92cfm
20median 7892
+17.9% vs. median
Average price$20,182
$10,318median $17,180$25k
+17.5% vs. median

Efficiency vs. peersvs. 42 in class

CFM per HP4.6cfm/hp
1median 3.94.6
+17.9% vs. median
Price per CFM$219$/scfm
$170median $226$1,262
-3.1% vs. median
