Hertz · SINGLE-STAGE ROTARY SCREW

HVD11-TMD-460-100

15 HP · electric · oil-flooded · 1-stage
AVERAGE PRICE
$14,556
2 retailers · in stock
Hertz HVD11-TMD-460-100

Hertz HVD11-TMD-460-100 is a 15 HP variable-speed rotary screw air compressor delivering 66 SCFM at 100 PSI on a 120-gallon tank, wired for 230V/3-phase. The HVD series is an oil-flooded single-stage screw design; TMD suffix denotes an integrated tank-mounted refrigerated dryer. Variable-speed drive adjusts output to meet demand, reducing energy costs at partial load. Unit weight is 683 lbs. List price approximately $20,437 through authorized Hertz distributors; dealer quote required. Key specs: 15 HP, 66 SCFM @ 100 PSI, 120-gal tank, 230V/3-phase, oil-flooded screw, integrated refrigerated dryer, 683 lbs.

HP
15
CFM
66 @ 100 PSI
Duty
continuous
Tank size
120 gal
Air output per horsepowerAirflow per motor HP
4.40CFM/HP
Poor 2.8Typical 3.15Good 3.5
Isentropic efficiencyClass median · 1-stage rotary screw
75%
Poor <50Good 70Best 92
Price per cubic foot · minuteVerified retailer price
$131$/SCFM
Good $180Typical $211High $260
PUMP & DRIVE
Stages1-stage screw
Cylinder
Pump RPM
Lubricationoil-flooded
Oil
Sump
Pump life
Pump material
Head material
Intercooler
PERFORMANCE
Catalog CFM66 @ 100 PSI
CFM / HP4.40
Cut-in / out
Tank fill
Est. draw13.2 kW
COST & MAINTENANCE
Electric · yearlyEst. $4,727
Maintenance · yearlyEst. $375
ELECTRICAL & FORM
Serviceelectric
Voltage460/3
Amps
Motor
Motor RPM
Control
Starter
Weight683 lb
Form— · 120 gal
BUILD & ENVIRONMENT
Air outlet
Drain
Drain outlet
ASME tank
Made in USA
Noise
Op. temp
Dimensions
Ship weight
Warranty

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog
1655 units
Peer class
44 · 15 HP
Sizing & pricevs. 44 in class
  • SCFM @ 15 HP66cfm
    20median 55.571
    +19% vs. median
  • Average price$14,556
    $9,196median $14,432$25k
    +0.8% vs. median
Efficiency vs. peersvs. 44 in class
  • CFM per HP4.4cfm/hp
    1.33median 3.734.73
    +18.1% vs. median
  • Price per CFM$310$/scfm
    $153median $251$905
    +23.3% vs. median

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

$7,733$12,281$16,830$21,378avg $14,556today-10d-20d-30d
