AVERAGE PRICE
$32,126
1 retailer
The FS-Curtis FNV22CXX (NxV22) is a 30-HP single-stage oil-injected variable-speed rotary screw air compressor delivering 116.1 CFM at 125 PSI (up to 175 PSI max), in a base-mounted (tankless) configuration. It uses a belt-driven airend with air cooling on a 3-phase motor. Rated for 100% continuous duty. Backed by the NXGEN 5-year / 10-year airend warranty.
HP
30
CFM
116.1 @ 125 PSI
Duty
100% continuous
Tank size
— gal
Air output per horsepowerAirflow per motor HP
3.87CFM/HP
Poor 2.8Typical 3.15Good 3.5
Isentropic efficiencyClass median · 1-stage rotary screw
75%
Poor <50Good 70Best 92
Price per cubic foot · minuteVerified retailer price
$277$/SCFM
Good $180Typical $211High $260
PUMP & DRIVE
Stages1-stage screw
Cylinder—
Pump RPM—
Lubricationoil-flooded
Oilcompressor oil (oil-injected)
Sump—
Pump life—
Pump material—
Head material—
Intercooler—
PERFORMANCE
Catalog CFM116.1 @ 125 PSI
CFM / HP3.87
Cut-in / out—
Tank fill—
Est. draw26.3 kW
COST & MAINTENANCE
Electric · yearlyEst. $9,453
Maintenance · yearlyEst. $750
ELECTRICAL & FORM
Serviceelectric
Voltage230/460-3
Amps—
Motor—
Motor RPM—
Control—
Starter—
Weight1477 lb
FormHorizontal
BUILD & ENVIRONMENT
Air outlet—
Drain—
Drain outlet—
ASME tank—
Made in USA—
Noise72 dBA
Op. temp—
Dimensions—
Ship weight—
Warranty—
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1708 units
- Peer class
- 35 · 30 HP
Sizing & pricevs. 35 in class
- SCFM @ 30 HP116.1cfm94median 120141-3.3% vs. median
- Average price$32,126$15,452median $24,529$35k+31% vs. median
Efficiency vs. peersvs. 35 in class
- CFM per HP3.87cfm/hp3.13median 44.7-3.3% vs. median
- Price per CFM$277$/scfm$120median $193$298+43.1% vs. median
Where this is sold1 verified retailer · USD
Find an installer / dealer near youAuthorized FS-Curtis dealers · search by ZIPPrice history
Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.
Compressors Now
