What horsepower is the FS-Curtis FNV18C1X air compressor?

The FS-Curtis FNV18C1X is rated at 25 HP.

How much air does the FS-Curtis FNV18C1X produce?

The FS-Curtis FNV18C1X delivers 99.6 SCFM at 125 PSI.

What is the maximum pressure of the FS-Curtis FNV18C1X?

The FS-Curtis FNV18C1X has a maximum operating pressure of 175 PSI.

What size tank does the FS-Curtis FNV18C1X have?

The FS-Curtis FNV18C1X has a 120-gallon horizontal tank.

Is the FS-Curtis FNV18C1X single-stage or two-stage?

The FS-Curtis FNV18C1X is a single-stage compressor.

What voltage does the FS-Curtis FNV18C1X require?

The FS-Curtis FNV18C1X runs on 230/460-3.

Is the FS-Curtis FNV18C1X oil-free or oil-lubricated?

The FS-Curtis FNV18C1X is oil-flooded.

What is the duty cycle of the FS-Curtis FNV18C1X?

The FS-Curtis FNV18C1X has a 100% duty cycle.

FS-Curtis FNV18C1X – 25 HP 120-Gallon Screw Air Compressor

The FS-Curtis FNV18C1X (NxV18) is a 25-HP single-stage oil-injected variable-speed rotary screw air compressor delivering 99.6 CFM at 125 PSI (up to 175 PSI max), on a 120-gallon ASME air receiver. It uses a belt-driven airend with air cooling on a 3-phase motor. Rated for 100% continuous duty. Backed by the NXGEN 5-year / 10-year airend warranty.

CFM

99.6 @ 125 PSI

Duty

100% continuous

Tank size

120 gal

Air output per horsepowerAirflow per motor HP

3.98CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage rotary screw

75%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$309$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage screw

Cylinder—

Pump RPM—

Lubricationoil-flooded

Oilcompressor oil (oil-injected)

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM99.6 @ 125 PSI

CFM / HP3.98

Cut-in / out—

Tank fill—

Est. draw21.9 kW

COST & MAINTENANCE

Electric · yearlyEst. $7,878

Maintenance · yearlyEst. $625

ELECTRICAL & FORM

Serviceelectric

Voltage230/460-3

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight1917 lb

FormHorizontal · 120 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise72 dBA

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1707 units
Peer class: 29 · 25 HP

Sizing & pricevs. 29 in class

SCFM @ 25 HP99.6cfm
84median 100204
-0.4% vs. median
Average price$30,824
$15,719median $23,082$48k
+33.5% vs. median

Efficiency vs. peersvs. 29 in class

CFM per HP3.98cfm/hp
3.38median 48.16
-0.4% vs. median
Price per CFM$309$/scfm
$157median $209$312
+47.6% vs. median

Where this is sold

Compressors Now
Verified 3 weeks ago
$30,824
Lowest

Find an installer / dealer near youAuthorized FS-Curtis dealers · search by ZIP

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

Compressors Now
