What horsepower is the FS-Curtis FNB15BXDTHXXX air compressor?

The FS-Curtis FNB15BXDTHXXX is rated at 20 HP.

How much air does the FS-Curtis FNB15BXDTHXXX produce?

The FS-Curtis FNB15BXDTHXXX delivers 80 SCFM at 125 PSI.

What size tank does the FS-Curtis FNB15BXDTHXXX have?

The FS-Curtis FNB15BXDTHXXX has a 0-gallon horizontal tank.

Is the FS-Curtis FNB15BXDTHXXX single-stage or two-stage?

The FS-Curtis FNB15BXDTHXXX is a single-stage compressor.

What voltage does the FS-Curtis FNB15BXDTHXXX require?

The FS-Curtis FNB15BXDTHXXX runs on 230/1.

Is the FS-Curtis FNB15BXDTHXXX oil-free or oil-lubricated?

The FS-Curtis FNB15BXDTHXXX is oil-flooded.

What is the duty cycle of the FS-Curtis FNB15BXDTHXXX?

The FS-Curtis FNB15BXDTHXXX has a 100% duty cycle.

What is the FS-Curtis FNB15BXDTHXXX best for?

The FS-Curtis FNB15BXDTHXXX is best suited for FS-Curtis FNB15BXDTHXXX screw air compressor for industrial use.

FS-Curtis FNB15BXDTHXXX

FS-Curtis FNB15BXDTHXXX is a 20 HP fixed-speed rotary screw air compressor delivering 80 SCFM at 125 PSI, base-mounted (no tank), wired for 230V single-phase. Oil-flooded lubrication and 100% duty cycle support continuous industrial operation. The NxB15 configuration includes an integrated air dryer, making it a turnkey solution for moisture-sensitive applications. Tri-voltage capability. Priced at approximately USD 17673 (Compressed Air Advisors, May 2021). Known gaps: weight not confirmed; noise level (dB) and primary-source OEM datasheet URL not verified for this MPN.

CFM

80 @ 125 PSI

Duty

100% continuous

Tank size

— gal

Air output per horsepowerAirflow per motor HP

4CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage rotary screw

75%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$221$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage screw

Cylinder—

Pump RPM—

Lubricationoil-flooded

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM80 @ 125 PSI

CFM / HP4

Cut-in / out—

Tank fill—

Est. draw17.6 kW

COST & MAINTENANCE

Electric · yearlyEst. $6,302

Maintenance · yearlyEst. $500

ELECTRICAL & FORM

Serviceelectric

Voltage230/1

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight1046 lb

FormHorizontal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 42 · 20 HP

Sizing & pricevs. 42 in class

SCFM @ 20 HP80cfm
20median 7892
+2.6% vs. median
Average price$17,673
$10,318median $17,180$25k
+2.9% vs. median

Efficiency vs. peersvs. 42 in class

CFM per HP4cfm/hp
1median 3.94.6
+2.6% vs. median
Price per CFM$221$/scfm
$170median $226$1,262
-2.4% vs. median

Where this is sold

Compressedairadvisors
Verified 2 months ago
$17,673
