What horsepower is the FS-Curtis FNB08BXDTHXXX air compressor?

The FS-Curtis FNB08BXDTHXXX is rated at 10 HP.

How much air does the FS-Curtis FNB08BXDTHXXX produce?

The FS-Curtis FNB08BXDTHXXX delivers 40 SCFM at 125 PSI.

What size tank does the FS-Curtis FNB08BXDTHXXX have?

The FS-Curtis FNB08BXDTHXXX has a 0-gallon horizontal tank.

Is the FS-Curtis FNB08BXDTHXXX single-stage or two-stage?

The FS-Curtis FNB08BXDTHXXX is a single-stage compressor.

What voltage does the FS-Curtis FNB08BXDTHXXX require?

The FS-Curtis FNB08BXDTHXXX runs on 230/1.

Is the FS-Curtis FNB08BXDTHXXX oil-free or oil-lubricated?

The FS-Curtis FNB08BXDTHXXX is oil-flooded.

What is the duty cycle of the FS-Curtis FNB08BXDTHXXX?

The FS-Curtis FNB08BXDTHXXX has a 100% duty cycle.

What is the FS-Curtis FNB08BXDTHXXX best for?

The FS-Curtis FNB08BXDTHXXX is best suited for FS-Curtis FNB08BXDTHXXX screw air compressor for industrial use.

FS-Curtis FNB08BXDTHXXX

FS-Curtis FNB08BXDTHXXX is a 10 HP fixed-speed rotary screw air compressor delivering 40 SCFM at 125 PSI, base-mounted (no tank), wired for 230V single-phase. Oil-flooded lubrication and continuous-duty design. The NxB08 configuration includes an integrated air dryer for turnkey moisture control in production and shop-air environments. Priced at approximately USD 12913 (Compressed Air Advisors, May 2021). Known gaps: weight, duty cycle percentage, noise level (dB), and primary-source OEM datasheet not confirmed for this MPN.

CFM

40 @ 125 PSI

Duty

100% continuous

Tank size

— gal

Air output per horsepowerAirflow per motor HP

4CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage rotary screw

75%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$323$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage screw

Cylinder—

Pump RPM—

Lubricationoil-flooded

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM40 @ 125 PSI

CFM / HP4

Cut-in / out—

Tank fill—

Est. draw8.8 kW

COST & MAINTENANCE

Electric · yearlyEst. $3,151

Maintenance · yearlyEst. $250

ELECTRICAL & FORM

Serviceelectric

Voltage230/1

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight868 lb

FormHorizontal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 59 · 10 HP

Sizing & pricevs. 59 in class

SCFM @ 10 HP40cfm
20median 39.845
+0.6% vs. median
Average price$12,913
$4,547median $11,392$26k
+13.4% vs. median

Efficiency vs. peersvs. 59 in class

CFM per HP4cfm/hp
2median 44.5
0% vs. median
Price per CFM$323$/scfm
$185median $282$903
+14.2% vs. median
