The FS-Curtis FML25C98BXA-D9N1S1 is a 25 HP two-stage pressure-lubricated reciprocating piston air compressor delivering 84 SCFM @ 175 PSI on a 240-gallon horizontal tank, wired for 230 V single-phase. The FML-Series uses pressure lubrication (force-fed oil) rather than splash lubrication, extending bearing life under sustained high-load industrial duty cycles. Suited for body shops, larger fabrication facilities, and production lines requiring high-volume 175 PSI air continuously. Key specs: 25 HP, 84 SCFM @ 175 PSI, 240-gal horizontal tank, 230/1-phase, two-stage pressure lubrication. Gaps: weight, full-load amps, noise level (dB), duty cycle, and OEM datasheet URL not confirmed from a primary FS-Curtis source.
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1708 units
- Peer class
- 23 · 25 HP
- SCFM @ 25 HP84cfm82median 88192-4.5% vs. median
- Average price$23,426$8,397median $17,200$50k+36.2% vs. median
- CFM per HP3.36cfm/hp3.3median 3.567.68-5.6% vs. median
- Price per CFM$279$/scfm$94median $196$474+41.6% vs. median
