FCT55

FS-Curtis FCT55 is a 5 HP two-stage reciprocating bare pump delivering 17.8 SCFM at 175 PSI maximum on a horizontal 80-gallon ASME-rated receiver, wired 230V single-phase. Cast-iron cylinders and heads with splash lubrication provide long service life in industrial duty applications. The intercooler includes an ASME-approved safety valve. At 124 lb the FCT55 is a direct replacement pump for the CT55 platform, suitable for shop, industrial, and OEM integration applications requiring continuous high-pressure output. V-belt drive runs at reduced RPM to lower heat and wear. Two-stage compression achieves higher efficiency than single-stage above 125 PSI. Verified retail pricing runs $1,468-$1,720 from authorized distributors. The FCT55 ships as a bare pump without tank, motor, or controls, requiring system integration. Series: FS-Curtis CT. MPN: FCT55. Key specs: HP: 5; SCFM at 175 PSI: 17.8; max PSI: 175; tank (as configured): 80 gal; voltage: 230/1; stages: 2; lubrication: splash; weight: 124 lb; config: simplex horizontal.
