What horsepower is the FS-Curtis FCT10C75H1S air compressor?

The FS-Curtis FCT10C75H1S is rated at 10 HP.

How much air does the FS-Curtis FCT10C75H1S produce?

The FS-Curtis FCT10C75H1S delivers 29.7 SCFM at 175 PSI.

What size tank does the FS-Curtis FCT10C75H1S have?

The FS-Curtis FCT10C75H1S has a 120-gallon vertical tank.

Is the FS-Curtis FCT10C75H1S single-stage or two-stage?

The FS-Curtis FCT10C75H1S is a two-stage compressor.

What voltage does the FS-Curtis FCT10C75H1S require?

The FS-Curtis FCT10C75H1S runs on 230/1.

What is the FS-Curtis FCT10C75H1S best for?

The FS-Curtis FCT10C75H1S is best suited for Compressed air supply for automotive and light-industrial shops.

FS-Curtis FCT10C75H1S – 10 HP 120-Gal 2-Stage Air Compressor

The FS-Curtis FCT10C75H1S is a 10 HP two-stage splash-lubricated reciprocating air compressor in the FS-Curtis CT Series. It delivers 29.7 SCFM at 175 PSI from a 2-cylinder CT75 pump and a 120-gallon horizontal ASME-certified receiver tank.

CFM

29.7 @ 175 PSI

Duty

— continuous

Tank size

120 gal

Air output per horsepowerAirflow per motor HP

2.97CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 2-stage piston

67%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$187$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages2-stage recip

Cylinder—

Pump RPM—

Lubricationsplash

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM29.7 @ 175 PSI

CFM / HP2.97

Cut-in / out—

Tank fill—

Est. draw8.8 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $3,151

Maintenance · yearlyEst. $250

Savings with Compressor Controller · yearlyEst. $725–$1,323

ELECTRICAL & FORM

Serviceelectric

Voltage230/1

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight833 lb

FormVertical · 120 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 127 · 10 HP

Sizing & pricevs. 127 in class

SCFM @ 10 HP29.7cfm
17median 34.279
-13.2% vs. median
Average price$5,930
$3,400median $7,494$27k
-20.9% vs. median

Efficiency vs. peersvs. 127 in class

CFM per HP2.97cfm/hp
1.72median 3.427.96
-13.2% vs. median
Price per CFM$187$/scfm
$99median $210$517
-11.2% vs. median
