FCA07E57H8U-A9L1XX

The FS-Curtis FCA07E57H8U-A9L1XX is a 7.5 HP two-stage oil-lubricated reciprocating piston compressor delivering 23.2 SCFM at 175 PSI on an 80-gallon ASME vertical tank, wired for 230V single-phase. Part of the FS-Curtis FCA series, this simplex unit uses cast-iron two-stage piston construction for industrial-grade duty in fabrication shops, automotive service bays, and mid-tier production cells. The two-stage design compresses air in two steps, improving efficiency and reducing heat versus single-stage units at the same output. Priced at approximately $5,117, the FCA07E57H8U-A9L1XX targets buyers needing continuous shop air at sustained pressure without the cost of rotary screw. Key specifications: 7.5 HP motor, 23.2 SCFM at 175 PSI, 80-gallon tank, 230V/1-phase, two-stage piston, oil-lubricated, simplex configuration. Dealer network provides installation and service support.
