The Champion PL-70A is a 30 HP two-stage gas-engine reciprocating pump unit delivering 25.6 SCFM at 175 PSI, mounted on a 30-gallon vertical tank, pressure-lubricated, weighing 590 lbs. Part of the Champion PL series of portable gas-powered compressors for job-site and remote field use. Rated 100% duty cycle. Simplex configuration with a single two-stage cast-iron pump. Gas power type eliminates need for electrical hookup; 120V circuit for electric start. Priced approximately $11,249 (All Tire Supply, May 2026). Key gaps: RPM and displacement not recorded; max_psi field shows 125 PSI (likely cut-out pressure), SCFM rated at 175 PSI; OEM datasheet not confirmed.
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1655 units
- Peer class
- 24 · 30 HP
- SCFM @ 30 HP77.5cfm77median 99.1203-21.8% vs. median
- Average price$11,259$11,317median $20,778$45k-45.8% vs. median
- CFM per HP2.58cfm/hp2.58median 3.376.79-23.3% vs. median
- Price per CFM$161$/scfm$116median $187$460-14.1% vs. median
Price history
Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.
