What horsepower is the Champion HQR10-12 air compressor?

The Champion HQR10-12 is rated at 10 HP.

How much air does the Champion HQR10-12 produce?

The Champion HQR10-12 delivers 33.5 SCFM at 175 PSI.

What size tank does the Champion HQR10-12 have?

The Champion HQR10-12 has a 120-gallon horizontal tank.

Is the Champion HQR10-12 single-stage or two-stage?

The Champion HQR10-12 is a two-stage compressor.

What voltage does the Champion HQR10-12 require?

The Champion HQR10-12 runs on 230/3.

What is the duty cycle of the Champion HQR10-12?

The Champion HQR10-12 has a 80% duty cycle.

What is the Champion HQR10-12 best for?

The Champion HQR10-12 is best suited for Low-noise shop and fleet-maintenance compressed air in occupied work areas.

Champion HQR10-12 – 10 HP 120-Gallon 2-Stage Air Compressor

Champion HQR10-12 is a 10 HP reciprocating industrial air compressor delivering 33.5 SCFM @ 175 PSI on a 120-gallon tank in a simplex configuration. Unit weight is 1,647 lbs. Retail price is approximately $11,395. Retailer data records 1 stage and 120V supply; both values warrant verification: a 10 HP compressor at 175 PSI is typically two-stage, and 120V is not a standard supply for this HP class. Buyers should confirm stage count, voltage supply, and orientation with Champion or an authorized distributor before ordering. The HQR Series represents Champion industrial heavy-duty reciprocating line. Gaps: stage count, voltage, OEM datasheet URL, and dB rating not confirmed from primary source.

CFM

33.5 @ 175 PSI

Duty

80% continuous

Tank size

120 gal

Air output per horsepowerAirflow per motor HP

3.35CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 2-stage piston

67%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$341$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages2-stage recip

Cylinder—

Pump RPM720 rpm

Lubricationsplash

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM33.5 @ 175 PSI

CFM / HP3.35

Cut-in / out—

Tank fill—

Est. draw8.8 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $3,151

Maintenance · yearlyEst. $250

Savings with Compressor Controller · yearlyEst. $725–$1,323

ELECTRICAL & FORM

Serviceelectric

Voltage230/3

Amps—

Motor—

Motor RPM—

Controllow-oil stop control + electronic tank drain

Starter—

Weight1647 lb

FormHorizontal · 120 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise65 dBA

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 127 · 10 HP

Sizing & pricevs. 127 in class

SCFM @ 10 HP33.5cfm
17median 34.279
-2% vs. median
Average price$11,419
$3,555median $7,494$27k
+52.4% vs. median

Efficiency vs. peersvs. 127 in class

CFM per HP3.35cfm/hp
1.72median 3.427.96
-2% vs. median
Price per CFM$366$/scfm
$103median $210$517
+73.6% vs. median
