Champion D6-AS-230/1 is a 5 HP single-stage rotary screw air compressor delivering 18 SCFM at 145 PSI on an 80-gallon vertical tank, wired for 230V single-phase, oil-lubricated, 100% duty cycle. The D-series simplex vertical configuration weighs 880 lbs. Maximum working pressure is 145 PSI. Priced at approximately $10,732. Continuous-duty screw design suits small manufacturing cells and shop air requiring reliable sustained output. The 80-gallon vertical receiver provides adequate buffer for moderate pneumatic tool demand. Gaps: no OEM datasheet URL confirmed; no noise level data.
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1655 units
- Peer class
- 42 · 5 HP
- SCFM @ 5 HP18cfm16median 19.922-9.5% vs. median
- Average price$10,492$5,810median $8,607$11k+21.9% vs. median
- CFM per HP3.6cfm/hp3.2median 3.984.4-9.5% vs. median
- Price per CFM$596$/scfm$267median $423$709+40.6% vs. median
Price history
Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.
