What horsepower is the Bostitch BTFP02012 air compressor?

The Bostitch BTFP02012 is rated at 1 HP.

How much air does the Bostitch BTFP02012 produce?

The Bostitch BTFP02012 delivers 2.6 SCFM at 90 PSI.

What is the maximum pressure of the Bostitch BTFP02012?

The Bostitch BTFP02012 has a maximum operating pressure of 150 PSI.

What size tank does the Bostitch BTFP02012 have?

The Bostitch BTFP02012 has a 6-gallon pancake tank.

Is the Bostitch BTFP02012 single-stage or two-stage?

The Bostitch BTFP02012 is a single-stage compressor.

What voltage does the Bostitch BTFP02012 require?

The Bostitch BTFP02012 runs on 120V.

What is the Bostitch BTFP02012 best for?

The Bostitch BTFP02012 is best suited for Trim carpentry, brad and finish nailing, small inflation and light tire work..

Bostitch BTFP02012 – 1 HP 6-Gallon Pancake Air Compressor

Bostitch BTFP02012 is a 1 HP industrial reciprocating piston compressor delivering 2.6 SCFM at 90 PSI on a 6-gallon tank, running 120V. Rated for 25% duty.

CFM

2.6 @ 90 PSI

Duty

— continuous

Tank size

6 gal

Air output per horsepowerAirflow per motor HP

2.60CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage piston

58%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$61$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage recip

Cylinder—

Pump RPM—

Lubrication—

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM2.6 @ 90 PSI

CFM / HP2.60

Cut-in / out120 / 150 PSI

Tank fill—

Est. draw0.9 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $315

Maintenance · yearlyEst. $80

Savings with Compressor Controller · yearlyEst. $72–$132

ELECTRICAL & FORM

Service120V Electric

Voltage120V

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight29 lb

FormPancake · 6 gal · 200 PSI tank rating

BUILD & ENVIRONMENT

Air outlet3/8 in NPT

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp40–104 °F

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1708 units
Peer class: 15 · 1 HP

Sizing & pricevs. 15 in class

SCFM @ 1 HP2.6cfm
2median 3.417
-23.5% vs. median
Average price$175
$129median $1,243$3k
-85.9% vs. median

Efficiency vs. peersvs. 15 in class

CFM per HP2.6cfm/hp
2.2median 3.417.3
-23.5% vs. median
Price per CFM$61$/scfm
$13median $253$965
-75.9% vs. median
