What horsepower is the Atlas Copco SF 22 air compressor?

The Atlas Copco SF 22 is rated at 30 HP.

How much air does the Atlas Copco SF 22 produce?

The Atlas Copco SF 22 delivers 86.8 SCFM at 100 PSI.

What is the maximum pressure of the Atlas Copco SF 22?

The Atlas Copco SF 22 has a maximum operating pressure of 116 PSI.

What size tank does the Atlas Copco SF 22 have?

The Atlas Copco SF 22 has a 0-gallon floor tank.

Is the Atlas Copco SF 22 single-stage or two-stage?

The Atlas Copco SF 22 is a single-stage compressor.

What voltage does the Atlas Copco SF 22 require?

The Atlas Copco SF 22 runs on 200-230/460.

What is the duty cycle of the Atlas Copco SF 22?

The Atlas Copco SF 22 has a 100% duty cycle.

Atlas Copco SF 22

Atlas Copco SF 22 is a 2-30 hp-class single-stage scroll compressor delivering 86.5 CFM (2.45 m³/min) FAD per ISO 1217 ed. 4 2009 Annex C. Air-cooled cooling, elektronikon mk5 graphic controller (upgrade); es4i & es6i central controllers (with mk5 upgrade) control. ISO 8573-1 Class 0 (oil-free certified).

CFM

86.8 @ 100 PSI

Duty

100% continuous

Tank size

— gal

Air output per horsepowerAirflow per motor HP

2.89CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage scroll

70%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$556$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage scroll

Cylinder—

Pump RPM—

Lubricationoil-free scroll

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM86.8 @ 100 PSI

CFM / HP2.89

Cut-in / out—

Tank fill—

Est. draw26.3 kW

COST & MAINTENANCE

Electric · yearlyEst. $9,453

Maintenance · yearlyEst. $750

ELECTRICAL & FORM

Serviceelectric

Voltage200-230/460

Amps—

Motor—

Motor RPM1750 rpm

Control—

Starter—

Weight1515 lb

FormFloor

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise65 dBA

Op. temp40–104 °F

Dimensions64 x 29 x 48 in

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1708 units
Peer class: 2 · 30 HP

Sizing & pricevs. 2 in class

SCFM @ 30 HP86.8cfm
86median 95.9105
-9.5% vs. median
Average price$22,599
$22,599median $22,599$23k
0% vs. median

Efficiency vs. peersvs. 2 in class

CFM per HP2.89cfm/hp
2.89median 3.53.5
-17.3% vs. median
Price per CFM$260$/scfm
$260median $260$261
-0% vs. median

Where this is sold

Atlas Copco Shop (SF22+ high canopy 460V)
Verified 3 weeks ago
$48,244
Lowest

Find an installer / dealer near youAuthorized Atlas Copco dealers · search by ZIP

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

Atlas Copco Shop (SF22+ high canopy 460V)
