What horsepower is the Anest Iwata OFT-20D air compressor?

The Anest Iwata OFT-20D is rated at 20 HP.

How much air does the Anest Iwata OFT-20D produce?

The Anest Iwata OFT-20D delivers 60 SCFM at 120 PSI.

What size tank does the Anest Iwata OFT-20D have?

The Anest Iwata OFT-20D has a 240-gallon tank.

Is the Anest Iwata OFT-20D single-stage or two-stage?

The Anest Iwata OFT-20D is a two-stage compressor.

What voltage does the Anest Iwata OFT-20D require?

The Anest Iwata OFT-20D runs on 208-230/460.

Is the Anest Iwata OFT-20D oil-free or oil-lubricated?

The Anest Iwata OFT-20D is oil-free.

What is the duty cycle of the Anest Iwata OFT-20D?

The Anest Iwata OFT-20D has a 100% duty cycle.

What is the Anest Iwata OFT-20D best for?

The Anest Iwata OFT-20D is best suited for Industrial oil-free duplex piston compressor for pharmaceutical, semiconductor, food/beverage, and medical applications requiring Class Zero air..

Anest Iwata OFT-20D – 20 HP 240-Gallon Air Compressor

Anest Iwata OFT-20D is a 10 HP × 2 oilless reciprocating piston duplex tank-mounted system delivering 60 CFM at 120 PSI for medical and lab applications.

CFM

60 @ 120 PSI

Duty

100% continuous

Tank size

240 gal

Air output per horsepowerAirflow per motor HP

3CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 2-stage piston

67%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$423$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages2-stage recip

Cylinder—

Pump RPM—

Lubricationoilless

OilN/A – oil-free design (no oil contacts air)

Sump—

Pump life30,000 hrs

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM60 @ 120 PSI

CFM / HP3

Cut-in / out—

Tank fill—

Est. draw17.6 kW

COST & MAINTENANCE

Compressor Controller ROI calc · $0.14/kWh · 1920 hr/yr · 70% motor efficiency · HP×1.10 sizing · savings 23–42% of electric

Electric · yearlyEst. $6,302

Maintenance · yearlyEst. $500

Savings with Compressor Controller · yearlyEst. $1,450–$2,647

ELECTRICAL & FORM

Service—

Voltage208-230/460

Amps—

Motor—

Motor RPM1750 rpm

Control—

Starter—

Weight—

Form— · 240 gal · 150 PSI tank rating

BUILD & ENVIRONMENT

Air outlet1 in NPT

DrainManual ball valve standard

Drain outlet—

ASME tankYes

Made in USA—

Noise—

Op. temp40–104 °F

Dimensions70 x 52 x 59 in

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 40 · 20 HP

Sizing & pricevs. 40 in class

SCFM @ 20 HP60cfm
58median 7092
-14.3% vs. median
Average price$25,363
$7,848median $15,562$39k
+63% vs. median

Efficiency vs. peersvs. 40 in class

CFM per HP3cfm/hp
2.92median 3.54.61
-14.3% vs. median
Price per CFM$423$/scfm
$98median $202$589
+109.1% vs. median

Where this is sold

Compressorsnow
Verified 2 months ago
$25,363
Lowest

Find an installer / dealer near youAuthorized Anest Iwata dealers · search by ZIP

Price history

Showing the current verified price for each retailer. As the price-tracking worker collects new readings, dots will appear along each line.

Compressorsnow
