ABAC AS-5501TMD is a 5-HP oil-flooded rotary screw air compressor delivering 20.00 SCFM at 150 PSI maximum on an 80-gallon tank, wired for 230V single-phase, with an integrated refrigerated dryer. The TMD suffix indicates tank mount with dryer: the refrigerated dryer removes moisture from compressed air, preventing water carryover to spray paint booths, CNC controls, and pneumatic tooling. The AS-5501TMD delivers the same output as the AS-5503TMD but the model-code suffix variations reflect dealer ordering or regional catalog differences within the ABAC AS-5 series. Shipping weight is 571 lb. List price is approximately ,607. ABAC is an Atlas Copco brand manufactured to ISO standards. Continuous-duty single-stage screw design supports sustained demand without duty-cycle limits. Single-phase 230V wiring suits facilities without three-phase service. Confirm dryer dewpoint and inlet temperature rating with the dealer.
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1655 units
- Peer class
- 42 · 5 HP
- SCFM @ 5 HP17.4cfm16median 19.922-12.6% vs. median
- Average price$8,607$5,810median $8,607$11k0% vs. median
- CFM per HP3.48cfm/hp3.2median 3.984.4-12.6% vs. median
- Price per CFM$495$/scfm$267median $423$709+16.7% vs. median
