The ABAC AS-20253TMD is a 20 HP rotary screw air compressor delivering 80 SCFM at 125 PSI on a 240-gallon horizontal tank, wired for 230V single-phase, oil-flooded. Machine weight is 908 lbs. Single-stage, simplex, continuous-duty design with no piston reciprocation. The 240-gallon receiver provides substantial storage volume, extending on-intervals and stabilizing pressure under peak demand. Max working pressure is 125 PSI, which suits most manufacturing and shop air networks and reduces energy consumption compared to 150 PSI-rated variants. Model suffix TMD indicates tank-mounted with dryer included. Oil-flooded screw element delivers quiet, efficient output. Suitable for automotive body shops, fabrication facilities, and production lines requiring steady 60 to 80 SCFM at moderate line pressure. Single-phase wiring allows installation without three-phase service.
Where this sits in the catalog
Histograms below: highlighted bar marks this unit’s bucket.
- Catalog
- 1655 units
- Peer class
- 42 · 20 HP
- SCFM @ 20 HP60.6cfm20median 7892-22.3% vs. median
- Average price$15,127$10,318median $17,526$25k-13.7% vs. median
- CFM per HP3.03cfm/hp1median 3.94.6-22.3% vs. median
- Price per CFM$250$/scfm$170median $226$1,262+10.3% vs. median
