What horsepower is the ABAC AS-15503TMD air compressor?

The ABAC AS-15503TMD is rated at 15 HP.

How much air does the ABAC AS-15503TMD produce?

The ABAC AS-15503TMD delivers 46.4 SCFM at 150 PSI.

What size tank does the ABAC AS-15503TMD have?

The ABAC AS-15503TMD has a 60-gallon horizontal tank.

Is the ABAC AS-15503TMD single-stage or two-stage?

The ABAC AS-15503TMD is a single-stage compressor.

What voltage does the ABAC AS-15503TMD require?

The ABAC AS-15503TMD runs on 230/1.

Is the ABAC AS-15503TMD oil-free or oil-lubricated?

The ABAC AS-15503TMD is oil-flooded.

What is the duty cycle of the ABAC AS-15503TMD?

The ABAC AS-15503TMD has a 0% duty cycle.

What is the ABAC AS-15503TMD best for?

The ABAC AS-15503TMD is best suited for ABAC AS-15503TMD screw air compressor for industrial use.

ABAC AS-15503TMD

ABAC AS-15503TMD is a 15 HP single-stage rotary screw air compressor delivering 60 SCFM at 150 PSI on a 60-gallon horizontal tank, wired for 230V single-phase, oil-flooded lubrication. The TMD suffix denotes tank-mounted duplex-ready configuration. Weighing 871 lbs. Maximum working pressure is 150 PSI. Priced at approximately $12,451. Continuous-duty screw design for sustained plant air and manufacturing cells. The integrated 60-gallon receiver reduces pressure drops during peak demand. Gaps: no duty cycle percentage; no OEM datasheet URL confirmed; no noise level data.

CFM

46.4 @ 150 PSI

Duty

— continuous

Tank size

60 gal

Air output per horsepowerAirflow per motor HP

3.09CFM/HP

Poor 2.8Typical 3.15Good 3.5

Isentropic efficiencyClass median · 1-stage rotary screw

75%

Poor <50Good 70Best 92

Price per cubic foot · minuteVerified retailer price

$268$/SCFM

Good $180Typical $211High $260

PUMP & DRIVE

Stages1-stage screw

Cylinder—

Pump RPM—

Lubricationoil-flooded

Oil—

Sump—

Pump life—

Pump material—

Head material—

Intercooler—

PERFORMANCE

Catalog CFM46.4 @ 150 PSI

CFM / HP3.09

Cut-in / out—

Tank fill—

Est. draw13.2 kW

COST & MAINTENANCE

Electric · yearlyEst. $4,727

Maintenance · yearlyEst. $375

ELECTRICAL & FORM

Serviceelectric

Voltage230/1

Amps—

Motor—

Motor RPM—

Control—

Starter—

Weight871 lb

FormHorizontal · 60 gal

BUILD & ENVIRONMENT

Air outlet—

Drain—

Drain outlet—

ASME tank—

Made in USA—

Noise—

Op. temp—

Dimensions—

Ship weight—

Warranty—

Where this sits in the catalog

Histograms below: highlighted bar marks this unit’s bucket.

Catalog: 1655 units
Peer class: 44 · 15 HP

Sizing & pricevs. 44 in class

SCFM @ 15 HP46.4cfm
20median 55.571
-16.3% vs. median
Average price$12,451
$9,196median $14,432$25k
-13.7% vs. median

Efficiency vs. peersvs. 44 in class

CFM per HP3.09cfm/hp
1.33median 3.734.73
-17% vs. median
Price per CFM$268$/scfm
$153median $251$905
+6.8% vs. median
